Setup Microsoft Entra ID SSO
This integration enables authentication via OpenID Connect (OIDC) using Microsoft Entra ID (formerly Azure Active Directory).
Overview
Seemore integrates with Microsoft Entra ID using:
OIDC (OpenID Connect) — user authentication through your organization's Microsoft identity platform
This setup allows Entra ID administrators to:
Let users sign in with their work or school Microsoft accounts
Centralize access control in Microsoft Entra ID
Automated user provisioning (SCIM) for Microsoft Entra ID is not available at this time. Invite users from Seemore so they receive an invitation and can complete sign-in with Entra ID.
Prerequisites
Before you start:
Admin rights in both Microsoft Entra ID (or help from your Azure AD administrator) and Seemore (workspace administrator).
An Entra ID tenant (your organization's directory in Microsoft Azure).
The tenant domain for your directory (for example
contoso.onmicrosoft.com). You can find it in the Microsoft Entra admin center under Identity > Overview > Primary domain, or follow Microsoft's guidance for locating your tenant ID and domain.
Setup Steps
Step 1 — Register an application in Microsoft Entra ID
Sign in to the Azure portal and open Microsoft Entra ID (Azure Active Directory).
Go to App registrations > New registration.
Configure:
Name: a clear name such as
SeemoreSupported account types: choose the option that matches who should sign in (for example, Accounts in this organizational directory only for a single-tenant app).
Under Redirect URI, select Web and enter:
https://datamaze.us.auth0.com/login/callback. You can add or edit redirect URIs later under Authentication.Select Register.
On the app Overview page, note the Application (client) ID — you will need the client ID in Seemore.
Create a client secret:
Go to Certificates & secrets > Client secrets > New client secret.
Add a description and expiry, then Add and copy the Value (secret). Store it securely; it will not be shown again.
Under Token configuration, Add optional claim:
Token type: ID
Enable email so user profiles in Seemore receive a reliable email identifier when available.
Under API permissions, add Microsoft Graph delegated permissions as needed for your organization. At minimum, User.Read is commonly used so users can sign in and the application can read basic profile information. Directory.Read.All is optional and may require administrator approval.
If your Microsoft Entra ID users do not have a mail attribute populated, optional email claims may still be empty. In that case, ensure users have a valid email in their profile, or work with your administrator to align mail and sign-in names with your identity policies.
Step 2 — Grant admin consent (if required)
After registering the application, you may need to grant organization-wide consent before users can sign in. Whether this is required depends on your tenant's consent policies.
In the Azure portal, go to Enterprise applications and open the enterprise application that corresponds to your app registration (or use App registrations > your app > API permissions).
Use Grant admin consent for [your organization] when prompted and when you have the appropriate administrator role (for example Global Administrator or Privileged Role Administrator, depending on your policy).
If Grant admin consent is unavailable, your account may not have permission to consent on behalf of the organization. Ask a Global Administrator to grant consent, or use your organization's documented admin-consent process.
Step 3 — Configure Microsoft Entra ID SSO in Seemore
In Seemore, open Settings > Preferences > Authentication.
Select Microsoft Entra ID and open the connection form.
Verify that the Redirect URI (callback URL) displayed on the form matches the URI you registered in Azure (
https://datamaze.us.auth0.com/login/callback).Enter:
Tenant domain — your Entra ID primary domain (for example
contoso.onmicrosoft.com). Use the primary domain for your tenant, not a GUID.Application (client) ID — from the app registration Overview in Azure.
Client secret — the secret value you created in Azure.
Save the connection.
Step 4 — Test sign-in and invitations
From Seemore, invite a user who belongs to your Entra ID tenant (or use an existing test account).
Open the invitation link in a browser session and complete sign-in with Microsoft when prompted.
Confirm you are returned to Seemore and signed in successfully.
If you only need to verify the connection without invitations, use your organization's normal sign-in flow (for example, Sign in with Microsoft or your workspace's SSO entry point) as configured for your tenant.
Troubleshooting
Sign-in fails with an invalid or expired secret
Client secret expired or mistyped
Create a new client secret in Azure and update it in Seemore Settings > Preferences > Authentication > Microsoft Entra ID.
User profile has no email
mail not set in Entra ID, or email token claim not issued
Add optional email in Token configuration; ensure the user has a contact email where appropriate.
Error about "unmanaged" organization or domain
Microsoft directory is not fully managed for your domain
Verify your organization's custom domain in Azure and complete the DNS steps Microsoft recommends so the domain is managed in the correct tenant.
Grant admin consent is disabled
Insufficient permissions
Use an account with rights to grant tenant-wide consent, or ask your Microsoft Entra administrator to approve the app.
Validation checklist
✅ App registration in Microsoft Entra ID includes the correct redirect URI from Seemore ✅ Client ID and client secret are saved in Seemore ✅ A test user can sign in and land in Seemore ✅ User appears in Seemore with the expected identity (email or UPN, depending on your configuration)
